Paper Tube Crush Strength Tester UP-3034

Product Introduction:

UP‑6034 Paper Tube Crush Strength Tester is equipped with touchscreen interface and auto‑return function. It is applied to measure flat compression strength and deformation of industrial paper tubes, chemical‑fiber paper tubes, plastic tubes, small cartons, paper cups, paper bowls and other small containers. Adopting single‑chip microcomputer control and precision ball‑screw drive, this tester supports data storage, statistical calculation and high‑speed thermal printout, fully meets ISO 11093‑9, ideal for paper‑tube manufacturers and quality inspection laboratories.

Product Highlights:

1.Touchscreen operation with auto‑return function after test completion

2.Precision ball‑screw drive, aluminium‑alloy panel, stable and durable hardware structure

3.Adjustable test speed 1‑50 mm/min and return speed 1‑80 mm/min

4.Supports test‑data memory and statistical processing; high‑speed thermal printer for report output

5.High parallelism of pressure plates (＜0.15 mm), ensures repeatable and accurate compression test results

6.Compact desktop design, lightweight for QC lab routine testing

Testing Standards:

ISO 11093‑9

Send email to us

Product Detail

SERVICE AND FAQ:

Product Tags

FAQ

Q1: What samples can UP‑6034 crush strength tester test?

A: It tests industrial paper tubes, chemical‑fiber paper tubes, plastic tubes, paper cups, paper bowls and other small containers for flat compression strength and deformation.

Q2: Which standard does this machine comply with?

A: It meets ISO 11093‑9 for paper tube compression test requirements.

Q3: Does the machine have auto‑return function?

A: Yes. It is equipped with auto‑return function after finishing each test, together with touch‑screen control and thermal printer for data output.

Q4: Can test data be stored?

A: Test data can be saved for review, and supports automatic statistical processing and printed reports.

Specification

Measurement range	(30 ~ 4000) N
Resolution	1N
Accuracy	+ -1%
Test speed adjustable range	(1 ~ 50) mm/min
Return speed adjustable range	(1-80) mm/min
Horizontal pressure plate parallel	less than 0.15mm
Upper and lower pressure plate test spacing	(40 ~ 180) mm
Upper and lower pressure plate dimensions (length x width)	180mm x 180mm
Dimensions (long X width X height)	330mmX350mmX630mm
Quality	about 41kg
Power	AC220V, 50Hz

Previous: Transportation Simulation Vibration Tester UP-6032

Next: Box Compression Tester UP-6035

Our service:

During the whole business process, we offer Consultative Selling service.

1) Customer inquiry process:Discussing testing requirements and technical details, suggested suitable products to customer to confirm. Then quote the most suitable price according to customer requirements.

2) Specifications customize process:Drawing related drawings to confirm with customer for customized requirements. Offer reference photos to show the appearance of the product. Then, confirm the final solution and confirm the final price with the customer.

3) Production and delivery process:We will produce the machines according to confirmed PO requirements. Offering photos to show the production process. After finishing production, offer photos to the customer to confirm again with the machine. Then do own factory calibration or third party calibration(as customer requirements). Check and test all the details and then arrange packing. Deliver the products is confirmed shipping time and inform the customer.

4) Installation and after-sale service:Defines installing those products in the field and providing after-sales support.

FAQ:

1. Are you a Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?Yes, we are the one of professional Manufacturers like Environmental Chambers, Leather shoe testing equipment, Plastic Rubber testing Equipment… in China. Every machine purchased from our factory has 12 months warranty after shipment. Generally, we offer 12 months for FREE maintenance. while considering sea transportation, we can extend 2 months for our customers.

Moreover, If your machine doesn’t work, you can send us an e-mail or call us we will try our best to find the problem through our conversation or by video chat if necessary. Once we have confirmed the problem, the solution will be offered within 24 to 48 hours.

2. What about the delivery term?For our standard machine which means normal machines, If we have stock in the warehouse, is 3-7 working days; If there is no stock, normally, the delivery time is 15-20 working days after payment received; If you are in urgent need, we will make a special arrangement for you.

3. Do you accept customization services? Can I have my logo on the machine?Yes, of course. We can not only offer standard machines but also customized machines according to your requirements. And we can also put your logo on the machine which means we offer OEM and ODM service.

4. How can I install and use the machine?Once you have ordered the testing machines from us, we will send you the operation manual or video in English version through Email. Most of our machine is shipped with a whole part, which means it is already installed, you just need to connect the power cable and start to use it.
