UP-2003 Versatile Peel Strength Testing Machine Compliant

Introducation:

Peel strength tester, is specifically used to determine the adhesive strength and peel performance of products such as adhesive products, composite films, packaging materials, etc.The peeling test of materials can reflect the bonding strength of the materials, which is an important test indicator for controlling the adhesive products from cracking and falling off.

By replacing different fixtures and testing fixtures, electronic peel testing machines can also perform:Tensile strength test,Heat sealing strength test,Tear strength test, Puncture force test,Low speed unwinding force test,Circular initial adhesion test.

Standards:

ASTM D3330,ASTM F88,ASTM D2861,ASTM B571,ASTM D1876,GB/T2790,GB/T2791,GB/T2792 and etc.

Send email to us

Product Detail

SERVICE AND FAQ:

Product Tags

Specification:

Item	Specification
Load Cell (Capacity)	10 kN to 300 kN (approximately 30 tons)
Force Resolution	1/300,000
Force Accuracy	≤0.5%
Displacement Resolution	1/1000 mm
Displacement Accuracy	≤0.1%
Metal Extensometer Resolution	1/1000 (subject to separate agreement)
Metal Extensometer Accuracy	≤0.5%
Large Strain Extensometer Accuracy	±0.01 mm (subject to separate agreement)
Speed Range	50 ~ 500 mm/min (custom speeds available upon request)
Travel Range (Stroke)	1000 mm (excluding fixtures; custom range available upon request)
Test Width	400 mm (custom width available upon request)
System Language	Switchable between Chinese and English
Power Supply	220V, 50Hz
Power Rating	Approx. 1000W
Machine Dimensions (L × W × H)	Approx. 500 × 500 × 1300 mm
Machine Weight	Approx. 100 kg

Features:

- High precision measurement: using high-precision force sensors, with an accuracy better than ± 1% required by ISO standards;

- Horizontal structure design: eliminates the influence of fixture weight and provides more accurate test results;

- Precision transmission system: stepper/servo motor drive, precision ball screw drive, smooth operation;

- Intelligent control system: microcomputer control, LCD screen display, menu based operation interface;

- Peak holding function: automatically records and holds the maximum peel force value;

- Automatic shutdown function: automatically shut down and maintain peak value after sample fracture;

- Overload protection: Over range automatic start protection to prevent equipment damage;

- Data output: optional micro printer, USB interface, supports computer online analysis;

Application:

Peel tensile tester is mainly used for performance testing of adhesives, adhesive tapes, stickers, composite films, protective films, release papers, medical patches, soft packaging materials, synthetic leather, woven bags, films, paper, electronic carriers, and other products such as peeling, shearing, and breaking.

Previous: Peel Tensile Testing Machine

Next:

Our service:

During the whole business process, we offer Consultative Selling service.

1) Customer inquiry process:Discussing testing requirements and technical details, suggested suitable products to customer to confirm. Then quote the most suitable price according to customer requirements.

2) Specifications customize process:Drawing related drawings to confirm with customer for customized requirements. Offer reference photos to show the appearance of the product. Then, confirm the final solution and confirm the final price with the customer.

3) Production and delivery process:We will produce the machines according to confirmed PO requirements. Offering photos to show the production process. After finishing production, offer photos to the customer to confirm again with the machine. Then do own factory calibration or third party calibration(as customer requirements). Check and test all the details and then arrange packing. Deliver the products is confirmed shipping time and inform the customer.

4) Installation and after-sale service:Defines installing those products in the field and providing after-sales support.

FAQ:

1. Are you a Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?Yes, we are the one of professional Manufacturers like Environmental Chambers, Leather shoe testing equipment, Plastic Rubber testing Equipment… in China. Every machine purchased from our factory has 12 months warranty after shipment. Generally, we offer 12 months for FREE maintenance. while considering sea transportation, we can extend 2 months for our customers.

Moreover, If your machine doesn’t work, you can send us an e-mail or call us we will try our best to find the problem through our conversation or by video chat if necessary. Once we have confirmed the problem, the solution will be offered within 24 to 48 hours.

2. What about the delivery term?For our standard machine which means normal machines, If we have stock in the warehouse, is 3-7 working days; If there is no stock, normally, the delivery time is 15-20 working days after payment received; If you are in urgent need, we will make a special arrangement for you.

3. Do you accept customization services? Can I have my logo on the machine?Yes, of course. We can not only offer standard machines but also customized machines according to your requirements. And we can also put your logo on the machine which means we offer OEM and ODM service.

4. How can I install and use the machine?Once you have ordered the testing machines from us, we will send you the operation manual or video in English version through Email. Most of our machine is shipped with a whole part, which means it is already installed, you just need to connect the power cable and start to use it.
