UP-6316 Sand Dust Resistance Test Chamber

Product Description：

The equipment can maintain a constant laboratory pressure or realize pressure adjustment, making it suitable for the testing of low-concentration dust pollution environments indoors. It is used to evaluate the sealing performance and corrosion degree of samples in such environments.

Product Application：

It is mainly used for testing the casings of control cabinets, household appliances, low-voltage appliances, automobiles, lighting fixtures, motorcycle parts, etc.

Send email to us

Product Detail

SERVICE AND FAQ:

Product Tags

Standards:

IEC60529

IEC 60598

GB2423.37-89

ISO 20653

GB4208

Features:

1, Uniformly synchronization hammer vibration dust emission device;

2, Auto adjust dust concentration 100mg/m³-60000mg/ m³

3, Interior chamber temperature and humidity control system;

4, Electrostatic eliminating device can avoid the dust on the chamber wall;

5, Automatic dust dehumidification system, to reduce the water content of dust and make sure dust in stable quality;

6, Available to supply EIA, JIS industrial dust, Arizona ash, butenandt cement, talc, Kanto sand dozens of respirable dust and not respirable dust;

7, Disposable dust belt, ensuring the safety of operator;

8, Automatic dust recovery device, reduce into chamber cleaning.

Technical Specifications:

Model	UP-6123
Test Type	F1	F2	F3	C
Interior dimensions	100100100cm (WDH)
Exterior dimensions	150120188cm (WDH)
Test Temp.	25~40ºC(natural temperature without control)
Test Humid.	45~85%RH(natural temperature without control)
Dust concentration	60000mg/m³	3000 mg/m³	100 mg/m³	100~5000 mg/m³
Dust spray period	1sec~99hr
Air source pressure	3~5kg/cm³
Power	AC 3¢220V 60HZ /3¢380V 50HZ

Previous: UP-6316 IP65 IP66 IP68 Sand Dust Ingress Dustproof Test Chamber

Next: UP-6316 Sand and Dus tproof Test Chamber

Our service:

During the whole business process, we offer Consultative Selling service.

1) Customer inquiry process:Discussing testing requirements and technical details, suggested suitable products to customer to confirm. Then quote the most suitable price according to customer requirements.

2) Specifications customize process:Drawing related drawings to confirm with customer for customized requirements. Offer reference photos to show the appearance of the product. Then, confirm the final solution and confirm the final price with the customer.

3) Production and delivery process:We will produce the machines according to confirmed PO requirements. Offering photos to show the production process. After finishing production, offer photos to the customer to confirm again with the machine. Then do own factory calibration or third party calibration(as customer requirements). Check and test all the details and then arrange packing. Deliver the products is confirmed shipping time and inform the customer.

4) Installation and after-sale service:Defines installing those products in the field and providing after-sales support.

FAQ:

1. Are you a Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?Yes, we are the one of professional Manufacturers like Environmental Chambers, Leather shoe testing equipment, Plastic Rubber testing Equipment… in China. Every machine purchased from our factory has 12 months warranty after shipment. Generally, we offer 12 months for FREE maintenance. while considering sea transportation, we can extend 2 months for our customers.

Moreover, If your machine doesn’t work, you can send us an e-mail or call us we will try our best to find the problem through our conversation or by video chat if necessary. Once we have confirmed the problem, the solution will be offered within 24 to 48 hours.

2. What about the delivery term?For our standard machine which means normal machines, If we have stock in the warehouse, is 3-7 working days; If there is no stock, normally, the delivery time is 15-20 working days after payment received; If you are in urgent need, we will make a special arrangement for you.

3. Do you accept customization services? Can I have my logo on the machine?Yes, of course. We can not only offer standard machines but also customized machines according to your requirements. And we can also put your logo on the machine which means we offer OEM and ODM service.

4. How can I install and use the machine?Once you have ordered the testing machines from us, we will send you the operation manual or video in English version through Email. Most of our machine is shipped with a whole part, which means it is already installed, you just need to connect the power cable and start to use it.
