UP-6119 High Temperature Muffle Furnace

The system is an integral high-temperature muffle furnace, which integrates the furnace body and the control part, greatly reducing the space occupied.It is mainly used in metallurgy, glass and ceramics

Refractory materials, crystals, electronic components, furnace manufacturing and small steel parts of the return, tempering and other high temperature heat treatment fields;It is also the ideal equipment for high temperature sintering.

Send email to us

Product Detail

SERVICE AND FAQ:

Product Tags

Purpose Overview:

Product features:

• Large screen LCD, whole machine integrated design, unique door furnace design, make the door operation more safe and convenient.

• The casing is made of high quality cold-rolled steel plate, and the casing seven colors is baked by high temperature, which makes it more durable.

Microcomputer PID temperature controller, accurate and reliable temperature control.

• Light weight and easy to move.

• Faster heating speed and more efficient use.

More reasonable appearance design, uniform temperature, more convenient use.

• With over current, over voltage, over heat, leakage, short circuit and other safety protection measures to ensure safer use.
• Good heat insulation effect, box wall and furnace with double - layer structure design, and ceramic fiber board as heat insulation material.

Specification:

Power	AC220V 50HZ		AC380V 50HZ		AC220V 50HZ		AC380V 50HZ
Max temperature	1000ºC				1200ºC
Use temperature	RT+50~950ºC				RT+50~1100ºC
Furnace material	ceramic fiber
Heat methods	Nickel chromium wire (molybdenum-containing)
Display mode	liquid crystal display
Temperature control mode	Programmed PID control
Input power	2.5KW	4KW	8KW	12KW	2.5KW	4KW	8KW	12KW
Work romm size W×D×H(mm)	120×200×80	200×300×120	250×400×160	300×500×200	120×200×80	200×300×120	250×400×160	300×500×200

Effective volume	2L	7L	16L	30L	2L	7L	16L	30L
* Under no load, no strong magnetism and no vibration, the test performance parameters are as follows: ambient temperature 20ºC, ambient humidity 50%RH.The type with "A" in the back is ceramic fiber furnace.
