UP-2005 High Temperature Chamber Test Machine


Microcomputer-controlled universal testing machine is a high-precision, multi-purpose material testing machine that tests the mechanical properties of various metal materials, non-metal materials, composite materials, and polymer materials in the state of tension, compression, bending, shearing, peeling , tearing and other mechanical properties.

Product Detail

Product Tags


1) Computer + Software control and display 6 kinds test curves: Force-displacement, force-deformation, stress-displacement, stress-deformation,force-time,displacement-time

2) Can be installed extensometer to test deformation of rubber or metal material

3) Can do high temperature test by high temperature oven and furnace

4) Can be installed all kinds of test fixtures, manual / hydraulic / pneumatic fixtures

5) Can be customized height, width, and follow any test standard or customer request

6) Also have Digital Display Type.

Technical Parameters

Max. load force 100KN
Load accuracy Class 1 (class 0.5 optional)
Load range 1%-100%FS (0.4%-100%FS optional)
Crosshead Travel(mm) 1000
Effective tensile space (mm) 700
Effective Test width (mm) 500
Crossbeam travel speed(mm/min) 0.001-500
Load resolution 1/300000
Round specimen clamping range(mm) 4-9, 9-14,14-20
Flat specimen clamping range(mm) 0-7, 7-14,14-20
Tensile grip Manual Wedge Fixture
Compression Plate(mm) Φ100x100 mm
Electronic Extensometer for metal material YUU10/50 (optional)
Large deformation extensometer for rubber DBX-800 (optional)
