TEMI880 Temperature And Humidity Controller

1. 5.7-inch color touch screen;
2. Two control methods (fixed value/program);
3. Sensor type: PT100 sensor (optional electronic sensor);
4. Contact input: input type: 1.RUN/STOP, 2.8-way DI fault input; input form: maximum contact capacity of 12V DC/10mA;
5. Contact output: maximum 20 points of contact (basic: 10 points, optional 10 points), contact capacity: maximum 30V DC/5A, 250V AC/5A;
6. Type of contact output:
   1).T1-T8: 8 o'clock
   2).Internal contact IS: 8 o'clock
   3).Time signal: 4 o'clock
   4).Temperature RUN: 1 point
   5).Humidity RUN: 1 point
   6).Temperature UP: 1 point
   7). Temperature DOWN: 1 point
   8). Humidity UP: 1 point
   9). Humidity DOWN: 1 point
   10).Temperature Soak: 1 point
   11). Humidity Soak: 1 point
   12).Drain: 1 point
   13).Fault: 1 point
   14).End of program: 1 point
   15).1st Ref: 1 point
   16).2nd Ref: 1 point
   17).Alarm: 4 points (optional alarm type)
7. Output type: voltage pulse (SSR)/(4-20mA) analog output; control output: 2 channels (temperature/humidity);
8. Can bring printer (USB function is optional);
9. Temperature measurement range: -90.00ºC--200.00ºC, error ±0.2ºC;
10. Humidity measurement range: 1.0--100%RH, error <1%RH;
11. Communication interface: (RS232/RS485, the longest communication distance is 1.2km [optical fiber up to 30km]), can be connected to a printer to print temperature and humidity curve monitoring data;
12. Program editing: 120 groups of programs can be edited, and each group of programs has a maximum of 100 segments;
13. Interface language type: Chinese/English, can be selected arbitrarily;
14. PID number/program connection: 9 groups of temperature, 6 groups of humidity/each program can be connected;
15. Power supply: power supply/insulation resistance: 85-265V AC, 50/60Hz;
Lithium batteries should be used for at least 10 years, withstand voltage of 2000V AC/1min.
