TEMI991 Electronic Pulse Valve Controller

Control the cold end solenoid valve and bypass the solenoid valve of the refrigeration system, adjust the refrigerant flow, achieve temperature balance, reduce cold and hot offset, and achieve energy-saving effects. At the same time, make temperature and humidity control more accurate, increase and decrease temperature quickly, accurately control the process, and achieve small overshoot, achieving linear temperature control. The display is clear and intuitive, with a strong three-dimensional sense. The programmable control system is flexible and convenient to operate, with stable performance, more efficient work, and flexible installation methods. It can be installed externally or embedded.

Send email to us

Product Detail

SERVICE AND FAQ:

Product Tags

Introduction:

Technical indicators:

1. 7-inch true color touch thin screen; TFT resolution: 800 × 480;
2. Control mode: program/fixed value;
Sensor type: two PT100 inputs (optional electronic sensor input);
4. Temperature measurement range: - 90.0 ºC~200.0 ºC (optional - 90.0 ºC~300.0 ºC), error ± 0.2 ºC;
5. Relative humidity measurement range: 1%~100%, error ± 1%;
6. Contact input: Input type: 1. RUN/STOP, 16-way DI fault input (expandable); Input form: maximum contact capacity: 12V DC/10mA;
7. Control output type: voltage pulse (SSR)/4-20mA analog output, control output: 2 channels (temperature/humidity), 2 channels (cold end/bypass);
8. Contact output: 16 points (optionally expandable), contact capacity: maximum 30V DC/5A, 250V AC/5A;
9. Contact output type:
(1) T1-T8: 8:00
(2) Internal contact IS: 8 points
(3) Time signal TS: 4 o'clock
(4) Temperature RUN: 1 point
(5) Humidity RUN: 1 point
(6) Temperature UP: 1 point
(7) Temperature DOWN: 1 point
(8) Humidity UP: 1 point
(9) Humidity DOWN: 1 point
(10) Temperature Soak: 1 point
(11) Humidity Soak: 1 point
(12) Drain: 1 point
(13) Fault: 1 point
(14) Program end: 1:00
(15) 1st Ref: 1 point
(16) 2nd Ref: 1 point
(17) Alarm: 4 points (optional alarm type);
10. Communication interface: RS232/RS485, with a maximum communication distance of 1.2km;
11. Interface language type: Chinese/English;
12. It has the function of inputting Chinese characters, editing and inputting manufacturer information, fault name, test name, etc., with intuitive and clear display;
13. Multiple signal combination relay outputs, and the signals can undergo logical operations (NOT, AND, OR, NOR, XOR), referred to as PLC programming capability;
14. Diversified relay control modes: parameter ->relay mode, relay ->parameter mode, logic combination mode, composite signal mode;
15. Program editing: 120 groups of programs can be programmed, with a maximum of 100 segments per group of programs, with all groups circulating and some segments circulating;
16. Curve: real-time display of temperature and humidity PV and SP curves; Historical curves can be queried online and exported from USB flash drives;
17. With network function, IP address can be set and can be remotely controlled;
18. Can bring a printer (USB function optional);
19. Power supply: DC 24V.
2, Specifications
Overall dimension: 194 × one hundred and thirty-three × 36 (mm) (length × wide × Deep)
Installation hole size: 189 × 128 (mm) long × Width)
