TEMI2502 temperature and humidity controller

5.7 inch true color touch thin screen; Two control methods: program/fixed value; Sensor type: Two PT100 inputs (optional electronic sensor input); Output method: Voltage pulse (SSR)/Control output: 2 channels (temperature/humidity)/2 channels 4-20mA analog output/16 channels relay output (passive). The display is clear and intuitive, with strong three-dimensional sense. The programmable control system is flexible and convenient to operate, with stable performance, more efficient work, and flexible installation methods. It can be installed externally or embedded.

Send email to us

Product Detail

SERVICE AND FAQ:

Product Tags

Introduction:

Specifications:

1. 5.7 inch true color touch thin screen;
2. Two control methods: program/fixed value;
3. Sensor type: Two PT100 inputs (optional electronic sensor input);
4. Output: Voltage pulse (SSR)/Control output: 2 channels (temperature/humidity)/2 channels 4-20mA analog output/16 channels relay output (passive)/DO contact output:
(1) T1-T8: 8pm
(2) Internal contact IS: 8 points
(3) Time signal: 4 o'clock
(4) Temperature RUN: 1 point
(5) Humidity RUN: 1 point
(6) Temperature UP: 1 point
(7) Temperature: 1 point
(8) Humidity UP: 1 point
(9) Humidity: 1 point
(10) Temperature Soak: 1 point
(11) Humidity Soak: 1 point
(12) Drain: 1 point
(13) Fault: 1 point
(14) Program end: 1 o'clock
(15) 1st Ref: 1 point
(16) 2nd Ref: 1 point
(17) Alarm: 4 points (optional alarm type)
5. Control signals: 16 DO control signals;
6. Alarm signal: 16 DI external fault alarms;
7. Temperature measurement range: -90.0 ºC -200.0 ºC (optional -90.0 ºC -300.0 ºC), with an error of ± 0.2 ºC;
8. Humidity measurement range: 1.0% -100%, error ± 1%;
9. Communication interface: RS232/RS485;
10. Interface language type: Chinese/English;
11. Equipped with Chinese character input function, editing and inputting manufacturer information, fault name, test name, etc., displaying intuitively and clearly;
12. Multiple signal combinations relay outputs, signals can be logically operated (NOT, AND, OR, NOR, XOR);
13. Diversified relay control modes: parameter ->relay mode, relay ->parameter mode, logic composite pattern, composite signal mode;
14. Program editing: It can program 120 groups of programs, with a maximum of 100 segments per group. All groups can cycle, while some segments can cycle;
15. Curve: Real-time display of temperature and humidity PV and SV curves;
16. With network function, an IP address can be set, and instruments can be remotely controlled;
17. Can come with a printer (USB function optional);
18. Power supply: 85-265V AC, 50/60Hz, I/O board power supply: DC 24V/600mA.

Previous: TEMI880 Temperature And Humidity Controller

Next: TEMI2702 Electronic Expansion Valve Controller
